Ecoponto 3Rc

01725

Model with modern metal and concrete design, belonging to the FRAME line.

Capacity Glass 20L (green), Paper 20L (blue), Organic 91L (brown) and Ashtray.

Street Furniture manufactured from painted metalized steel. Finishes available in painted metalized steel.

DESIGN BY Daniel Caramelo

MATERIALS AND FINISHES

MATERIAL TYPE

Metal Steel
Concrete

INTERNAL STRUCTURE

TREATMENT AND PROTECTION

Anti-corrosion treatment by metallization

COLOURS AND FINISHES

Other Finishes On Request

Tomar em consideração a diferença de cores de écrans e de impressão em relação à realidade.

A Amop não pode ser responsabilizada por diferenças de dores em relação a meios impressos ou digitais.

TECHNICAL INFORMATION

LENGTH / DIAMETER (CM)	WIDTH (CM)	HEIGHT / DIAMETER / THICKNESS (CM)	WEB.PESO_2 Part	FOUNDATION HEIGHT (CM)	INSTALLATION / APPLICATION
45	45	81	76		Surface permanent anchoring

LENGTH / DIAMETER (CM)

WIDTH (CM)

HEIGHT / DIAMETER / THICKNESS (CM)

FOUNDATION HEIGHT (CM)

WEIGHT (KG)

INSTALLATION / APPLICATION

Surface permanent anchoring

TARGET MARKET

Solution: Furniture and Equipment

Market: Public Spaces Semi-Public Space Residential Spaces

Usage: Outdoor

CHARACTERISTICS

Advantages and Benefits

Suitableness:

Resistant to atmospheric agents and vandalism.

Characteristics:

Painted Metallized Steel;
Round Steel Rod;
Pastel shades;
Strong and Comfortable.

Applications and Vocations

Public, Semi-Public And Residential Spaces:

Mechanical And Manual Installation And Handling;
Optional Anchoring To The Ground;
Low Maintenance.

HIGHLIGHTS

Edges: Rounded edge

Capacity: 91 Liters + 20L + 20L

Non-slip:

Sustainability:

Inclusivity:

COMPLEMENTARY

Accessories / addons:

Recommendations:

3 years

Smooth pigmented concrete;
Woods;
Painted metallized steel.

5 years

Smooth painted concrete;
Galvanized steel;
Recycled plastic;
HPL composites.

10 years

Shot blasted concrete;
Honed concrete;
Sandblasted concrete;
Stainless steel;
Corten steel.

ABOUT AMOP URBAN FURNITURE WARRANTY

The materials’ guarantee is assured by their performance against the functional, aesthetic and suitability requirements for the intended use, as well as their resistance to exposure to meteorological agents and climate change;
Beyond the 3 years legal manufacturer warranty, increased guarantees are provided on urban furniture for materials whose quality and finishing process ensure their stability throughout their life-cycle.

Exclusions:

Failure to comply with the terms defined in the general sales conditions ; Natural characteristics of materials, finishes and treatments; Damage caused by incorrect handling, transport, installation or use; Non-conductive connecting elements, parts and components made of the same material; Damage resulting from failure to comply with the manufacturer's recommendations and/or maintenance, cleaning and protection plan, when applicable; Non-cumulative guarantees.

GENERAL CONDITIONS OF SALE

- CGV General Sales Conditions of Amop

Exhibitions, Orders And Supplies

We facilitate the indication of local representatives and/or proximity exhibitions.

We can inform you about availability and/or deadlines for standard items.

Other colours and finishes on request.

Website, Catalogues And Samples

Amop cannot take responsibility for differences due to printing or digital media.

Please take into consideration a colour difference on your screen or printout compared to reality.

We recommend approval of the desired finish, upon presentation of a previous sample of the finish.

Product Quality

Amop cement-based products are susceptible to the phenomenon of efflorescence. This natural and technically unavoidable phenomenon does not affect the technical characteristics of the products or their durability, affecting only the aesthetic appearance of the material. Given the characteristics of the aggregates, AMOP is not responsible for slight variations in granulometry or tonality. Any existing claim on the material should be made before it is applied on site.

Reception And Storage

At the reception operation, the Client must check and control the conformity of the delivery against the order, regarding the quantity and quality of the materials, as well as the state of the packaging, late and tonality, dry, and totally protected from rain, since failure to respect the conditions mentioned here will lead to the appearance of the typical pathologies of cementitious products, commonly known as efflorescence (white spots) but also other pathologies that directly influence the visual appearance of the product.

Installation And Maintenance

It is important to comply with Amop
Amop cleaning and protection products are recommended for treatment.

General Conditions Of Sale

Amop General Conditions of Sale
